Lamps » Lamp service » Removal and installation
Overhead console reading lamp

REMOVAL

(1) Remove overhead console.

(2) Remove screws attaching reading lamp to overhead console (Fig. 14).

(3) Disconnect reading lamp harness connector.

(4) Separate lamp from vehicle.

Fig. 14 Overhead Console Reading Lamp Fig. 14 Overhead Console Reading Lamp

1 - DISPLAY MODULE

2 - LAMP

3 - SCREW

4 - SWITCHES

5 - SCREW

6 - LAMP

7 - SCREWS

8 - TERMINALS

INSTALLATION

(1) Position lamp in vehicle.

(2) Connect reading lamp harness connector.

(3) Install screws attaching reading lamp to overhead console.

(4) Install overhead console.
